Bigfoot Installation Guides:
Below grade footing form installation
For below grade applications simply attach the sonotube footing form to the construction tube with a minimum of four screws, place in the ground on top of undisturbed soil, or on 4" to 6" of compacted crushed stone or gravel, level, plumb and backfill. Use another footing form turned upside down as a funnel for pouring concrete into the tube.
Click for a more detailed look at below ground installation.
Above-ground precast concrete footing installation
For above ground applications, simply attach the required length of construction sonotube to the footing form with a minimum of four screws. Drill 3/8" (10mm) holes on a 45 degree angle in the footing form as indicated by the markings on the flange area at each rib location to accept a minimum of 12" (30cm) spikes.
Place the sonotube footing forms on undisturbed soil and drive spikes at a 45 degree angle inward so as to prevent the footing form from rising when concrete is being poured. Use another footing form turned upside down as a funnel for pouring concrete into the tube.
Click for a more detailed look at above ground installation.
Bigfoot has had its products tested by independent, recognized and accredited organizations.
Trust Bigfoot for hurricane resistant footings! View or print all or part of the Vertical-uplift testing (pdf) documents or the Horizontal testing (pdf) documents care of PSC Analytical Services (PDF files require Adobe Acrobat Reader. Download it now!)
Concrete footing form installation instructions
We strongly recommend that users of Bigfoot Systems® Footing Forms read the Installation Manual thoroughly before beginning a project. Take some time to view our step-by-step animations to see how easy it is to install Bigfoot!
